Jumbo Winder for Apparel & Fashion Textiles

Name: Jumbo Winder for Apparel & Fashion Textiles
Brand: Meera Industries Limied
SKU: 01-jumbo-winder-for-apparel-fashion-textiles
Rating: 4.3 (33 reviews)

Meera JW-300 Jumbo Winder for Apparel & Fashion Textiles

Large-package, knotless bobbin winding built for polyester and nylon filament weaving mills producing suiting, dress materials, sarees, and fashion fabrics on water-jet and air-jet looms.

★★★★☆ 4.3 based on 33 Google reviews

What this page covers, at a glance

60-position JW-300 winds 4–5 kg knotless bobbins from polyester, nylon, FDY, and DTY cheese or cylinder packages — directly cutting bobbin-change frequency on water-jet and air-jet looms.

Fine-denier, high-TPM/low-GSM apparel yarns including multifilament polyester and PP multifilament are handled at speeds from 200 to 800 MPM with individually driven spindles for consistent package build.

Individual motor-driven take-up and overfeed with V-type tension control delivers uniform density across all 60 positions — critical for weaving preparatory winding of filament yarns going into fashion fabrics.

Single-operator machine with up to 40% savings in power and floor space on a 19.1 m frame — a direct productivity argument for Surat-belt filament weaving mills producing high-volume apparel cloth.

Materials Jumbo Winder can process

Jumbo Winder handles these material types, grouped by family.

Polyester

Polyester FDY DTY

Polyolefin

Polyamide

Nylon

Filament Yarns

Frequently Asked Questions

Can the Meera JW-300 Jumbo Winder handle polyester FDY and DTY filament yarns at weaving speeds without package defects?

Yes — the Meera JW-300 Jumbo Winder processes polyester FDY and DTY filament yarns at speeds from 200 to 800 MPM with individual motor-driven take-up and overfeed at every position. The V-type knob-controlled tension device maintains uniform package density across the 300 mm bobbin traverse, producing knotless take-up packages of 4 to 5 kg that are dimensionally stable and ready for direct use on water-jet and air-jet looms.

How does the Meera JW-300 Jumbo Winder reduce bobbin change stoppages on water-jet and air-jet looms running nylon filament?

The JW-300 builds knotless take-up bobbins of 4 to 5 kg on 300 mm diameter cores, which are significantly larger than standard feed packages of up to 3 kg. Fewer, heavier bobbins mean fewer changeovers per shift on water-jet and air-jet looms, directly increasing loom running hours. Individual spindle drives across all 60 positions ensure each bobbin reaches the same package weight consistently, preventing early, unplanned loom stops.

Is the Jumbo Winder the same as a jumbo bobbin winder, or are they different machines?

Yes — jumbo winder and jumbo bobbin winder refer to the same product family. Both names describe high-capacity winding machines that build large-diameter, heavyweight yarn packages onto bobbins. The term jumbo bobbin winder emphasizes the output package form, while jumbo winder is the broader trade name. The Meera JW-300 is sold under both designations and produces 300 mm knotless bobbins of 4 to 5 kg per position.

When should a weaving mill choose the Meera JW-300 Jumbo Winder over winding directly from smaller cheese packages on the loom?

Choose the JW-300 when loom productivity losses from frequent bobbin changes outweigh the cost of a preparatory winding step. The JW-300 consolidates up to 3 kg cheese or cylinder feed packages into 4 to 5 kg knotless jumbo bobbins, cutting changeover frequency on high-speed water-jet and air-jet looms. For mills running polyester, nylon, or PP filament in continuous large-volume production, the 40 percent power and space efficiency gain reinforces the case further.

What input package quality does the Meera JW-300 Jumbo Winder need when processing PP multifilament yarn for weaving preparatory?

The JW-300 accepts PP multifilament yarn supplied on cheese or cylinder feed packages with a maximum weight of 3 kg per position. Package geometry must be compatible with the 600 mm spindle pitch and single-deck frame layout. Yarn speed, yarn type, and preset yarn length are all operator-configurable parameters, allowing the machine to accommodate variations in PP multifilament count and tension requirements without hardware changes between package lots.

What output package quality can a saree or dress-material weaving mill expect from the Meera JW-300 Jumbo Winder on polyester filament?

The JW-300 delivers knotless take-up bobbins of 4 to 5 kg wound on 300 mm outer diameter, 330 mm length cores, with uniform density maintained by individual motor-driven overfeed at every spindle. Each of the 60 positions is independently controlled, so package hardness and layer structure are consistent across the full machine width. The knotless build eliminates mid-fabric defects caused by knot passage through water-jet or air-jet loom guides.

What goes wrong if the tension setting on the Meera JW-300 Jumbo Winder is not matched to the nylon or polyester filament count being wound?

Incorrect tension on the JW-300's V-type knob-controlled tension device causes either loose, collapsing packages at low tension or over-tensioned, ribbon-wound packages that fuse filament layers and cause loom pick failures. Both defects increase waste and loom downtime. Because each spindle has independent motor-driven take-up, a tension error affects only the misconfigured position, but all 60 positions must be set correctly before a production run on a new filament count.
