Bulking And Heat Setting Machines for Carpets, Rugs & Flooring

Meera's BAH continuous heat setting line converts cabled Polyester, PP, Wool, and Polyamide yarn into supersoft, high-bulk finished yarn — purpose-built for tufted carpets, residential rugs, bathmats, and commercial flooring applications.

★★★★☆ 4.3 based on 33 Google reviews

What this page covers, at a glance

Processes Polyester, PP, PA, PET, Acrylic, and Wool yarns from 1,000 to 10,000 denier — covering everything from fine residential carpet yarn to heavy commercial flooring constructions.

Continuous inline process delivers 6–7 tons/day output across BCF carpet yarn production and high-volume carpet yarn manufacturing with up to 400 m/min yarn speed.

Pre-steamer and climate chamber (110–200 °C) lock in durable bulk and softness for bathmat yarn production, prayer mat yarns, and luxurious shaggy yarns alike.

Lowest steam consumption at 30 kg/h and electricity draw of 40 kWh keep per-kg operational cost minimal — critical for high-traffic commercial carpet yarn production at scale.

Applications in this sector

Bulking And Heat Setting Machines serves these specific applications within Carpets, Rugs & Flooring.

Other applications served

BCF Carpet Yarn Production
Bathmat Yarn Manufacturing
Alpaca Carpet Yarn Processing
Wool Carpet Yarn Production
BCF And Staple Carpet Yarns
High Bulk Yarns
High-volume Carpet Yarn Production
Carpet Manufacturing
Carpet Yarns
Carpet
BCF Carpet Yarn
Luxurious Shaggy & Bathmat Yarns
Strong Multi-ply & High-bulk Yarns
Natural Wool & Alpaca Carpet Yarns
Specialized Prayer Mat Yarns
High-traffic Commercial Carpets
Luxurious Residential Rugs
High-end Rugs
Prayer Mat Production
High-bulk Carpet Yarn Manufacturing
Bathmat Yarn Production
Commercial Carpet Yarn Production
Residential Carpets
Commercial Flooring
Bathmats & Rugs
Industrial Carpets
Carpet Yarn

Materials Bulking And Heat Setting Machines can process

Bulking And Heat Setting Machines handles these material types, grouped by family.

Polyolefins

Polyesters

Polyester

Polyamides

Nylon

Natural & Specialty

Wool Acrylic BCF Filament Yarns solution-dyed fibers Crimped Varieties

Frequently Asked Questions

Can the Meera BAH Bulking And Heat Setting Machine handle Wool and PP yarn in the same production run?

Yes — the Meera BAH machine is designed to run different deniers and fiber types simultaneously across its channels, including Wool, PP, Polyester, PA, PET, and Acrylic. The PLC-controlled touch panel lets operators set independent temperature and speed parameters per channel, and the heat setting chamber operates across a 110–200°C range to accommodate the distinct thermal requirements of each fiber type.

How does the Meera BAH machine prevent yarn breakage and snagging during continuous bulking and heat setting of multifilament polyester?

The BAH supply creel uses thread sensors that trigger an immediate machine stop when yarn breaks, preventing downstream tangle or waste. An anti-snagging disc with anti-static design keeps multifilament polyester ends separated at the creel, while guiding rollers at every direction change in the take-up winder eliminate friction points that could cause filament damage during high-speed winding at up to 400 m/min.

Is the Meera BAH Bulking And Heat Setting Machine the same as a continuous bulking and heat setting machine for carpet yarn?

Yes — the Meera BAH and the term continuous bulking and heat setting machine refer to the same product family. BAH is Meera's model designation; the broader trade term describes the inline process where cabled yarn is coiled, steam-bulked, heat-set, cooled, and wound in one uninterrupted pass. The BAH is specifically engineered for carpet and bathmat yarn rather than apparel or industrial yarn applications.

When should I choose the BAH continuous heat setting line over batch autoclave heat setting for carpet yarn production?

Choose the BAH continuous line when daily output requirements exceed 4 tons, since the BAH reaches up to 7 tons per day in a single pass from cabled input to finished package. Batch autoclaves require separate loading, sealing, and unloading cycles that interrupt flow and raise per-kg labor costs. The BAH also runs 3 operators per shift versus the larger crews typically needed to manage multiple autoclave batches at equivalent volume.

What input package specifications does the Meera BAH Bulking And Heat Setting Machine require for dope-dyed cabled polyester yarn?

Feed packages at the BAH supply creel must have a tube length of 290 mm, a minimum inside tube diameter of 45 mm, and a maximum outside package diameter of 250 mm. Net yarn weight per package is approximately 10 kg, though this varies with yarn density. The creel accommodates up to 64 ends total, with 350 mm spacing between packages to maintain a uniform, tangle-free yarn path.

What output bulk and package quality can I expect from the Meera BAH machine when processing 3600-denier PP yarn for tufted carpet?

For 3600-denier PP yarn, the BAH delivers approximately 7.0 tons of finished yarn per day as parallel cheese packages with a maximum outside diameter of 250 mm and up to 4 kg per package. The pre-steamer and climate chamber produce a durable, heat-set bulk effect with supersoft handle. The Teflon-coated conveyor and normalization zone ensure consistent bulk across all ends before the yarn is wound stress-free at up to 400 m/min.

What goes wrong if conveyor dwell time is set too short during heat setting of high-denier Nylon or PA carpet yarn on the BAH machine?

Insufficient dwell time prevents full steam penetration into high-denier Nylon or PA yarn, resulting in incomplete heat setting where the bulk effect is weak or uneven across the package. The yarn retains residual twist memory, producing carpet with inconsistent pile height and reduced resilience. The BAH conveyor belt is PLC-driven with an adjustable dwell range of 40 seconds to 6 minutes specifically to allow operators to match exposure time to denier and fiber type.
